Home > Hastelloy C22 Fasteners
Request For Our Latest Prices On Hastelloy C22 Fasteners in Riyadh, Saudi Arabia!
Hamad Fasteners in Riyadh, Saudi Arabia, is a trustworthy producer and supplier of high-performance fasteners, such as Hastelloy C22 fasteners. Used in highly corrosive and chemically aggressive conditions, these fasteners are recognized for their remarkable durability and strength. Hamad Fasteners manufactures and supplies these parts according to international standards, catering to chemical processing, petrochemical, pharmaceutical, and marine industries. With an emphasis on quality and accuracy, the company provides Hastelloy C22 fasteners that offer long-term reliability and safety in the most extreme applications.
The Hastelloy C22 fasteners are made of a majority of nickel (about 56%), supplemented with large percentages of chromium (20–22.5%), molybdenum (12.5–14.5%), and iron, along with small percentages of cobalt, tungsten, and others. This special alloy has superb resistance to a broad spectrum of corrosive media, such as oxidizing and reducing agents. Such fasteners have high tensile strength, usually ranging from 690 MPa, and possess superior mechanical stability even at higher temperatures. Their structure makes them well suited in environments where pitting, crevice corrosion, and stress corrosion cracking are issues.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy Fasteners | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy Fasteners | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Hastelloy C22 fasteners are widely utilized in chemical processing facilities, waste treatment plants, marine service, and pollution control devices. They are best suited for parts that are exposed to severe chemicals such as nitric acid, hydrochloric acid, and chlorine-bearing compounds. Uses are in heat exchangers, reactors, flanges, and piping systems where long-term corrosion resistance is required. These fasteners offer consistent performance in both reducing and oxidizing conditions and thus are a popular selection for maintaining structural integrity and safety in harsh industrial environments.
At Hamad Fasteners, we prioritize the protection and integrity of our Hastelloy C22 Fasteners with meticulous packaging. Each fastener is individually wrapped in anti-corrosive materials to prevent damage and maintain quality. We use robust, weather-resistant cartons or boxes, clearly labeled with product details for easy identification. Our packaging solutions are designed to withstand the rigors of shipping, ensuring safe and secure delivery. For added convenience, we offer customized packaging options tailored to specific customer needs and preferences.
Hamad Fasteners is one of the Industrial suppliers and manufacturers of quality fasteners in Riyadh, Saudi Arabia, that has spent more than 12 years serving various industries.
