Home > Hastelloy C22 Bolts
Request For Our Latest Prices On Hastelloy C22 Bolts in Riyadh, Saudi Arabia!
Hamad Fasteners, Riyadh, Saudi Arabia, is a well-established manufacturer and supplier of top-quality industrial fasteners such as Hastelloy C22 bolts. With their high corrosion resistance and strength, these bolts have been engineered to perform satisfactorily in extremely aggressive chemical environments. Hamad Fasteners makes sure that all the products are of international standards, catering to the chemical processing, petrochemical, and marine industries. A focus on quality and strength, the company offers Hastelloy C22 bolts with enduring performance for use in applications that require resistance to oxidizing and reducing agents.
The Hastelloy C22 bolts consist predominantly of nickel (56%), chromium (20%), molybdenum (14%), and iron (6%), with minor components of cobalt, manganese, and silicon. This specific composition of alloy has superior resistance against pitting, crevice corrosion, and stress corrosion cracking in reducing and oxidizing conditions. The bolts have high tensile strength, commonly ranging between 690 MPa, and they can withstand mechanical properties across a broad range of temperatures. The superior corrosion resistance of Hastelloy C22 renders the bolts very suitable for applications involving severe chemicals and high temperature.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy C22 Bolts | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 Bolts | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Hastelloy C22 bolts are commonly employed in industries where corrosion resistance is crucial, including chemical processing, pollution control, and marine environments. They are used in typical applications such as heat exchangers, reactors, valves, and piping systems in aggressive chemicals such as hydrochloric acid, sulfuric acid, and chlorine. They are particularly suitable for highly corrosive atmospheres and oxidizing and reducing agent-containing environments. Their chemical resistance and high hardness make them the preferred method for ensuring the reliability and longevity of essential industrial parts.
At Hamad Fasteners, we ensure that our Hastelloy C276 Bolts are installed with the highest level of care to maintain their quality and integrity. Each bolt is individually wrapped with protective and corrosion-resistant coatings to prevent damage during transport. We use sturdy and weatherproof boxes with clearly labeled product information for easy identification. Our packaging products are designed to withstand harsh shipping conditions, ensuring that your Hastelloy C276 bolts arrive in perfect condition, ready for immediate use quite. Custom packaging is also available to meet specific needs.
Hamad Fasteners is one of the Industrial suppliers and manufacturers of quality fasteners in Riyadh, Saudi Arabia, that has spent more than 12 years serving various industries.
