Request For Our Latest Prices on Stainless Steel 17-4 PH Bolts in Riyadh, Saudi Arabia!
Hamad Fasteners is proud to offer our premium Stainless Steel 17-4 PH Bolts and is a major manufacturer, supplier and exporter. With precision and expertise, our bolts meet the highest standards in the industry. Our commitment to quality ensures that every bolt provides exceptional strength, durability and corrosion resistance. Trust Hamad Fasteners offers reliable and high quality stainless steel 17-4 PH bolts, designed to perform well in demanding applications in a variety of industries.
Hamad Fasteners is a top producer and distributor of Riyadh, Saudi Arabia-based Stainless Steel 17-4 PH Bolts that provide the best fastening solutions in industries demanding superior strength, toughness, and resistance against corrosion. As a precipitation-hardening grade, 17-4 PH stainless steel has the strength of martensitic grades coupled with the corrosion resistance of austenitic grades, making it a very versatile product. These bolts may be heat-treated to different hardness levels, delivering consistent performance under high stress and corrosive environments. With excellent fatigue resistance, stress corrosion cracking resistance, and endurance through temperature extremes, they are suitable for aerospace, petrochemical, and marine applications.
| Specifications | ASTM A 193 / ASME SA 193 |
| Standard | DIN, ISO ,JIS ,GB, IS, BS, ASTM and all International Standards |
| Size | M3 – M100 | 3/6″ – 4″ | Custom Sizes |
| Fasteners Length | 3 mm – 200 mm | Custom Sizes |
| Bolts Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Head | Hex, Square, Round, Hex flange, Flat, T-head |
| Neck type | Hex, Square, Triangular, Oval & Knurled etc. |
| Surface Coating | Black Oxide, Cadmium, Galvanized, Teflon, Xylan, Zinc, Others Upon Request |
| Manufacturing Process | Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing. |
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-4 PH | 0.07 max | 0.15-0.45 | 15.00-17.50 | 3.00-5.00 | Bal | 1.0 max | 3.0-5.0 | 0.40 max | 0.03 max | 1.0 max |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
17-4 PH Bolts are made of iron, chromium (15–17.5%), nickel (3–5%), and copper (3–5%), with minimal additions of niobium for added precipitation hardening. They attain high mechanical hardness and strength by heat treatment, and tensile strength of up to 1310 MPa and yield strength of up to 1170 MPa in the H900 condition. These bolts possess superior toughness, hardness, and resistance to fatigue and corrosion and superior corrosion resistance in chemical and marine environments. They are able to retain strength at elevated and low temperatures, and therefore they are ideal for critical, high-performance applications.
Stainless Steel 17-4 PH Bolts are used extensively in aerospace, defense, chemical, and marine applications where strength and corrosion resistance are highly critical. They find their presence in aircraft parts, spacecraft assemblies, gas turbines, and nuclear power stations where mechanical integrity is the prime concern. In automotive and heavy industrial equipment, these bolts resist fatigue, cyclic stresses, and high pressures. Their strength and durability render them ideal for use on oil & gas platforms, chemical plants, and marine conditions, where corrosion resistance and mechanical strength are needed for safe, long-term operation.
Hamad Fasteners is one of the Industrial suppliers and manufacturers of quality fasteners in Riyadh, Saudi Arabia, that has spent more than 12 years serving various industries.
